01
- Provides analogue output for eight types of
thermocouples (R, S, K, E, J, T, B, N) two types of thermo-resistance
- (Cu 50 / PT-100), DC Voltages and resistance
- °C and °F scales selectable
- Suitable for the field use
- High Accuracy of 0.05%
- Display
: 5 Digits LCD
- Output provided
:-
- Voltages range
: -10mV to 110mV/-100mV to 1100mV
- Resolution :
0.01mV/0.1mV, Accuracy : ± 0.05%
- Resistance
: 0 to 400Ω
- Resolution :
0.1Ω, Accuracy : ± 0.05%
- R type thermocouple
: -40°C to 1760°C
- Resolution :
1°C, Accuracy : ± 0.05%
- S type thermocouple
: -20°C to 1760°C
- Resolution :
1°C, Accuracy : ± 0.05%
- B type thermocouple
: 400°C to 1800°C
- Resolution :
1°C, Accuracy : ± 0.05%
- E type thermocouple
: -200°C to 1000°C
- Resolution :
0.1°C, Accuracy : ± 0.05%
- K type thermocouple
: -200°C to 1370°C
- Resolution :
0.1°C, Accuracy : ± 0.05%
- J type thermocouple
: -200°C to 1200°C
- Resolution :
0.1°C, Accuracy : ± 0.05%
- T type thermocouple
: -200°C to 400°C
- Resolution :
0.1°C, Accuracy : ± 0.05%
- N type thermocouple
: -200°C to 1300°C
- Resolution :
0.1°C, Accuracy : ± 0.05%
- PT-100 sensor
: -200°C to 850°C
- Resolution :
0.1°C, Accuracy : ± 0.05%
- Cu50 Sensor
: -50°C to 150°C
- Resolution :
1°C, Accuracy : ± 0.05%
