CE-0303IM

  • Microprocessor Based Digital Multi function meter for three phase measurement.
  • PARAMETERS DISPLAYED:
  • VOLTAGE: Three phase Line to Line and Line to neutral Voltages with Autoranging to Kilo-Volt.
  • CURRENT: Three phase currents with Autoranging to Kilo-Amperes.
  • POWER: Three phase individual KW,KVA and KVAR with Autoranging to MW,MVA and MVAR.
  • Total (of three phases) KW, KVA and KVAR with Autoranging to MW, MVA and MVAR.
  • POWER FACTOR: Three phase individual Power factors and overall system Power Factor.
  • FREQUENCY: System frequency.
  • ENERGY: KWh, KVAh and KVARh.
  • MAXIMUM DEMAND: Demand in KW and KVA.
  • Password Protected.
  • Programmable CT/PT ratios.
  • Accuracy: 1% for Voltage, current, KWh, KVAh & KVARh. 2% for Power Parameters.
  • Display: 16 Character x 4 Lines Backlit LCD display.
  • Bezel Size: 96  X96 mm .
  • Auxiliary Power Supply: 230V AC 50Hz / 110V AC 50Hz

  • Microprocessor Based Digital Multi function meter for three phase measurement.
  • PARAMETERS DISPLAYED:
  • VOLTAGE: Three phase Line to Line and Line to neutral Voltages with Autoranging to Kilo-Volt.
  • CURRENT: Three phase currents with Autoranging to Kilo-Amperes.
  • POWER: Three phase individual KW,KVA and KVAR with Autoranging to MW,MVA and MVAR.
  • Total (of three phases) KW, KVA and KVAR with Autoranging to MW, MVA and MVAR.
  • POWER FACTOR: Three phase individual Power factors and overall system Power Factor.
  • FREQUENCY: System frequency.
  • ENERGY: KWh, KVAh and KVARh.
  • MAXIMUM DEMAND: Demand in KW and KVA.
  • Password Protected.
  • Programmable CT/PT ratios.
  • Accuracy: 1% for Voltage, current, KWh, KVAh & KVARh. 2% for Power Parameters.
  • Display: 16 Character x 4 Lines Backlit LCD display.
  • Bezel Size: 96  X96 mm .
  • Auxiliary Power Supply: 230V AC 50Hz / 110V AC 50Hz
